Known issues

Garmin maps format is not public, so map generation process (done with mkgmap) is based in reverse engineering. As format has not been completely deciphered yet, there's still a number of problems affecting the maps. They have the advantage that data on them are most probably more up to date than commercial ones, although in some areas coverage is lower. Another great advantage is that anyone can complete or correct missing or wrong data. Below there is a list of known issues regarding the use of the maps.

  • Address search: in order to find a given street using 'Search by address' option of the GPS it is necessary to type the name of the street exactly as it is on the map, e.g. 'Calle de los Derechos Humanos' (Human Rights Street). It may be a problem for languages like Spanish or French, in which the name of the way is preceded by the type of way: Avenida de América, Paseo de la Castellana, etc. as it will be difficult to know how the name of a street is in the map: it may be Calle Derechos Humanos, C/ de los Derechos Humanos, Avenida América, etc.
    To avoid this, some changes are introduced that let you omit the type of way and also particles before the main part of the name. For the examples above, typing “Derechos Humanos”, “América” or “Castellana” will be enough. Some irrelevant words common at the end of street names, like Avenue, Street, Road (English), Strasse, Weg (German), kalea, bidea (Basque), etc. are also removed.
  • Roundabouts exit number: if a way entering a roundabout shares a node with an exiting way, that exit is not taken into account for the 'Take exit # to the right' instruction, although on screen it is correctly displayed. In fact, it is caused by errors in the data used to generate the map, and must be fixed on OpenStreetMap data.

Correct and wrong roundabouts

  • Advanced functions: some advanced functions, such as lane indication, on screen speed limit display, crossing search, etc. don't work.
  • Topographic maps on MapSource: contour lines behavior in MapSource is quite variable, some times they are displayed and some times they are not, without a known motive, just showing the number that indicates the height but not the line. However, although they are not seen, they are there and can be used, for example, to calculate a route profile (Edit menu->Route Properties->Show Profile...). On BaseCamp and QLandkarte GT this problem doesn't occur.

If you detect any other problem in the maps, other than those due to errors or lacks in OpenStreetMap data, please use the comments at the en of this page to report it.

You can leave your comments on this page below:

Comments (31)

Topic: Problems
Sort
4/5 (14)
1 2 3 > Last
Facebookdel.icio.usStumbleUponDiggGoogle+Twitter
Gravatar
Full StarFull StarFull StarEmpty StarEmpty Star
Filipe Lemos (Torres Vedras, Portugal)
I just installed the latest version 17.03 of Portugal for Basecamp and the maps both TOPO and normal appear in Blue. Impossible to have a clear image of the maps.
12th August 2020 2:24pm
Gravatar
Full StarFull StarFull StarFull StarEmpty Star
Sander (Thailand)
I have just downloaded and installed the Topo map of Thailand, thank you.

However the contour lines are hardly visible, and my screen doesn't look as "clear" as the screenshots on your website.
Are there any settings that I can change to improve? I have read about TYP file, but this seems pretty complicated to edit.
11th July 2020 10:56am
Gravatar
Franz47 (Vienna, Austria)
Problem: Maps never appear any more after installing in Basecamp I had no problems for years with the maps from this website and earlier versions of Basecamp Windows. Now I have Basecamp 4.7.1 (the same problem was with 4.7.0) and cannot install the maps any more so they appear in Basecamp. i download xyz.zip, unpack it resulting in xyz.exe + xyz.gmap + install.txt files. I start xyz.exe and follow the installation procedure as usually, no error message. When I start Basecamp ... Read More
Admin:
Maps work on every BaseCamp version, that's not the problem. I guess you are changing path where maps are installed (maybe you are using the same path you did for older maps). Maps in *.gmap format must be in a given path, so that BaseCamp/MapSource are able to read them. You must not change default path selected by setup wizard.
4th March 2020 10:02am
Gravatar
Franz47 (Austria)
I now also tried on one of my older rarely used laptops with Basecamp 4.6.2, also Win 10 64 bit. Same problem. After a problemless installation procedure without error messages the map is not presented in the Basecamp map collection.
4th March 2020 2:51pm
Gravatar
Marco (Germany)
Unfortunately on a Garmin GPS device the OSM maps of Chile and Argentina do not work together. When only one of the above maps is installed everything works well, if both are installed only the Chilean map is displayed and Argentina is white without any information.
Admin:
Be aware that not all Garmin models are able to display more than one map, that's a limitation they have, not a problem of the maps. Alternatively, you can register and download South Ameria map, which contains all countries in a single map.
25th November 2019 8:58pm
